The Level-Spike is a fast and proven machine for the creation of aeration slits to aid drainage and allow air into turf surfaces. The Level-Spike can achieve a maximum depth of 25cm / 10” and as a range of optional knives to alter the slit pattern including hollow tines to pull cores
| Simple and effective | |
| Optional weight transfer kit for tough conditions | |
| Many blade options | |
| Consider the Level-Spike 1700 for a smaller areas |
Specifications
| SKU | S0001521 |
| Operation | Tractor mounted |
| Working width (m) | 2.4 |
| Working width (inch) | 96 |
| Max. Working depth (mm) | 250 |
| Max. Working depth (inch) | 10 |
| Weight (kg) | 495 |
| Weight (lbs) | 1090 |
| Slit distance between the knives (mm) | 150 |
| Slit distance between the knives (inch) | 6 |
| Hole spacing distance driving direction (mm) | 330 |
| Hole spacing distance driving direction (inch) | 13 |
| Min. Tractor HP required | 45 |
| Min. Lifting capacity 610 mm behind the lifting eyes (kg) | 600 |
| Min. Lifting capacity 24 inch behind the lifting eyes (lbs) | 1300 |
| Max. capacity ( m² hr) | 12000 |
| Max. capacity (ft² hr) | 108000 |
| Three-point hitch | 3-point CAT 1-2 |
| Lubricant | EP 2 |
Standard components
| Description | Quantity | Article number |
|---|---|---|
| Toolbox and manual | 1 | |
| Deep slit knife kit (x64) | 1 | 213.220.010 |
Options
| Description | Quantity | Article number |
|---|---|---|
| Rear roller kit | 1 | 213.220.002 |
| Truckster knife kit (x64) | 1 | 213.220.004 |
| Additional truckster knife kit (x32) | 1 | 213.220.006 |
| Fine slit knife kit (x360) | 1 | 213.220.008 |
| Additional Deep Slit Knife Kit (x32) | 1 | 213.220.012 |
| Hollow tine kit (x96) | 1 | 213.220.014 |
| Weight Transfer Kit (Can Be Used Without Wheel Kit) | 1 | 213.220.016 |
| Twist deep slit knife kit (x64) | 1 | 213.220.018 |
| Additional twist deep slit knife kit (x32) | 1 | 213.220.020 |
* Check availability in your region.
