Multivator 1800


The Multivator is a unique sports turf renovation implement carrying out de-compacting and top dressing by recycling buried soil/ root zone up to the surface and incorporating back into the root structure, saving time and money from importing materials.

Can remove up to 45 m³ per hectare at 130 mm working depth due to high blade density
Nine durable carbide tipped blades with 200 mm spacing between the blades as standard
Optional front knife roller ensures a uniform finish with minimal disruption
SKU 115.180.002
Operation Tractor pulled
Working width (m) 1.8
Working width (inch) 70.9
Max. Working depth (mm) Up to 140
Max. Working depth (inch) Up to 5.5
Weight (kg) 1050 (base machine) 1225 (base machine with hydraulic rearbrush)
Weight (lbs) 2315 (base machine) 2701 (base machine with hydraulic rearbrush)
Number of knives (blades) 36
Min. Tractor HP required 100-150
Min. Lifting capacity 610 mm behind the lifting eyes (kg) 3200
Min. Lifting capacity 24 inch behind the lifting eyes (lbs) 7055
Three-point hitch CAT 1 & 2
Gearbox oil 80W90 - 1.2 (2.3 L) (0.61 gal)
Lubricant EP 2
Description Quantity Article number
PTO Shaft 1
Blade with tip 10mm - 353.816.315 36 353.816.315
Description Quantity Article number
Hydraulic Rear Brush - 215.180.002 1 215.180.002
Front Knife Roller - 215.180.004 1 215.180.004
* This product may not be available for your region - Redexim reserves the right to change specification of products without prior notice, specifications of equipment may vary globally - illustrations are for visual representation only.
