The Multivator is a unique sports turf renovation implement carrying out de-compacting and top dressing by recycling buried soil/ root zone up to the surface and incorporating back into the root structure, saving time and money from importing materials.
| Can remove up to 45 m³ per hectare at 130 mm working depth due to high blade density | |
| Nine durable carbide tipped blades with 200 mm spacing between the blades as standard | |
| Optional front knife roller ensures a uniform finish with minimal disruption |
Specifications
| SKU | 115.180.002 |
| Operation | Tractor pulled |
| Working width (m) | 1.8 |
| Working width (inch) | 70.9 |
| Max. Working depth (mm) | Up to 140 |
| Max. Working depth (inch) | Up to 5.5 |
| Weight (kg) | 1050 (base machine) 1225 (base machine with hydraulic rearbrush) |
| Weight (lbs) | 2315 (base machine) 2701 (base machine with hydraulic rearbrush) |
| Number of knives (blades) | 36 |
| Min. Tractor HP required | 100-150 |
| Min. Lifting capacity 610 mm behind the lifting eyes (kg) | 3200 |
| Min. Lifting capacity 24 inch behind the lifting eyes (lbs) | 7055 |
| Three-point hitch | CAT 1 & 2 |
| Gearbox oil | 80W90 - 1.2 (2.3 L) (0.61 gal) |
| Lubricant | EP 2 |
Standard components
| Description | Quantity | Article number |
|---|---|---|
| PTO Shaft | 1 | |
| Blade with tip 10mm - 353.816.315 | 36 | 353.816.315 |
Options
| Description | Quantity | Article number |
|---|---|---|
| Hydraulic Rear Brush - 215.180.002 | 1 | 215.180.002 |
| Front Knife Roller - 215.180.004 | 1 | 215.180.004 |
* This product may not be available for your region - Redexim reserves the right to change specification of products without prior notice, specifications of equipment may vary globally - illustrations are for visual representation only.
