The punch-action Verti-Core III quickly cores turf surfaces while hold-down plates ensures no damage is caused to the surface in the process; Its belt drive systems ensure a high work-rate & neat hole pattern. The working depth can be easily adjusted as required by ground conditions and operators.
| High-Speed | |
| Optional side or top-eject tines | |
| Consider the Verti-Core III 2100 for larger areas |
Specifications
| SKU | 114.160.000 |
| Working width (m) | 1.6 |
| Working width (inch) | 63 |
| Max. Working depth (mm) | 100 |
| Max. Working depth (inch) | 4 |
| Weight (kg) | 846 |
| Weight (lbs) | 1865 |
| Hole spacing distance driving direction (mm) | 25 - 110 |
| Hole spacing distance driving direction (inch) | 1 - 4.3 |
| Min. Tractor HP required | 45 |
| Three-point hitch | 3-Point CAT 1 |
| Rpm Max. | 540 |
| Gearbox oil | SAE 90 |
| Lubricant | EP 2 |
Standard components
| Description | Quantity | Article number |
|---|---|---|
| Toolbox with combi tool and manual | 1 | |
| PTO Shaft | 1 | |
| Hollow Tine 21x12x125mm (13/16x1/2x5") | 24 | 9990075 |
Options
| Description | Quantity | Article number |
|---|---|---|
| Verti-Core III 1600 - Windrow Kit | 1 | 212.160.018 |
| Turf hold down kit multi tine block vc 1600 | 1 | 212.160.016 |
| Solid Tine 10x100mm (3/8x4") | 24 | 39200-447 |
| Chisel Tine 5x30x90mm (3/16x1 3/16x3 1/2") MD:19mm | 24 | 311.619.127 |
| Solid Tine 8x95 (5/16x 3 13/16") | 48 | 311.108.095 |
| Requires | ||
| Multi-Tine Kit - Verti-Core 1600 | 1 | 212.160.014 |
| Hollow Tine 10x6x80mm (3/8x1/4x3") | 48 | 311.210.080 |
| Requires | ||
| Multi-Tine Kit - Verti-Core 1600 | 1 | 212.160.014 |
| Cross Tine 12x90mm (1/2x3 1/2") MD: 8mm | 48 | 9990020 |
| Requires | ||
| Multi-Tine Kit - Verti-Core 1600 | 1 | 212.160.014 |
* This product may not be available for your region - Redexim reserves the right to change specification of products without prior notice, specifications of equipment may vary globally - illustrations are for visual representation only.
