Verti-Core III 1600


The punch-action Verti-Core III quickly cores turf surfaces while hold-down plates ensures no damage is caused to the surface in the process; Its belt drive systems ensure a high work-rate & neat hole pattern. The working depth can be easily adjusted as required by ground conditions and operators.

High-Speed
Optional side or top-eject tines
Consider the Verti-Core III 2100 for larger areas
SKU 114.160.000
Working width (m) 1.6
Working width (inch) 63
Max. Working depth (mm) 100
Max. Working depth (inch) 4
Weight (kg) 846
Weight (lbs) 1865
Hole spacing distance driving direction (mm) 25 - 110
Hole spacing distance driving direction (inch) 1 - 4.3
Min. Tractor HP required 45
Three-point hitch 3-Point CAT 1
Rpm Max. 540
Gearbox oil SAE 90
Lubricant EP 2
Description Quantity Article number
Toolbox with combi tool and manual 1
PTO Shaft 1
Hollow Tine 21x12x125mm (13/16x1/2x5") 24 9990075
Description Quantity Article number
Verti-Core III 1600 - Windrow Kit 1 212.160.018
Turf hold down kit multi tine block vc 1600 1 212.160.016
Solid Tine 10x100mm (3/8x4") 24 39200-447
Chisel Tine 5x30x90mm (3/16x1 3/16x3 1/2") MD:19mm 24 311.619.127
Solid Tine 8x95 (5/16x 3 13/16") 48 311.108.095
Requires
Multi-Tine Kit - Verti-Core 1600 1 212.160.014

Hollow Tine 10x6x80mm (3/8x1/4x3") 48 311.210.080
Requires
Multi-Tine Kit - Verti-Core 1600 1 212.160.014

Cross Tine 12x90mm (1/2x3 1/2") MD: 8mm 48 9990020
Requires
Multi-Tine Kit - Verti-Core 1600 1 212.160.014

Hollow Tine 16/7x110mm (5/8x1/4x4 3/8") MD:19 ((top ejecting)) 24 311.219.138
Hollow Tine 19x10x110mm (3/4x3/8x4 3/8") MD:19mm (top ejecting) 24 311.219.158
Hollow Tine 19x10x125mm (3/4x3/8x5") MD:19mm 24 311.219.159
Hollow Tine 1.0625 inch mounting 7/8 18 311.222.140
Requires
Tine Holder for 7/8'' Tine 6 466.122.554
or
Contra block 7/8 tine holder 6 472.302.554

* This product may not be available for your region - Redexim reserves the right to change specification of products without prior notice, specifications of equipment may vary globally - illustrations are for visual representation only.
