Compact cut-and-collect. Tractor-mounted. Easy to pick up, take tight turns, lower, and get to work. Low-dump clamshell hopper. Quickly opens at the back for seamless material ejection.
| Compact cut & collect | |
| Manoeuvrable in tight spaces | |
| Clamshell design, easy emptying |
Specifications
| SKU | S0001719 |
| Operation | PTO |
| Working width (m) | 1.5 |
| Working width (inch) | 59 |
| Max. Working depth (mm) | 30 |
| Max. Working depth (inch) | 1.2 |
| Hopper capacity (m3) | 1,1 |
| Hopper capacity (FT3) | 39 |
| Max. Working speed (km h) | 1-2 (scarifying) 1-5 (mowing) |
| Max. Working speed (mph) | 0.6-1.5 (scarifying) 0.6-6 (mowing) |
| Weight (kg) | 530 |
| Weight (lbs) | 1168 |
| Number of knives (blades) | 48 |
| Standard knife thickness (mm) | 3 |
| Standard knife thickness (inch) | 0.118 |
| Hopper capacity (L) | 1100 |
| Hopper capacity (cu.ft.) | 39 |
| Min. Tractor HP required | 38 |
| Three-point hitch | Cat. 1 |
| Gearbox oil | GL5 80W90 (1.1L / 1.16 qts.) |
| Dimensions (width mm) | 1880 |
| Dimensions (height mm) | 1570 |
| Dimensions (length mm) | 1850 |
| Dimensions (width inch) | 74 |
| Dimensions (height inch) | 61.8 |
| Dimensions (length inch) | 72.8 |
| Min. Hydraulic pressure (bar) | 120 |
| Min. Hydraulic pressure (psi) | 1.740 |
| Max. Tire pressure (bar) | 120 |
| Max. tire pressure (psi) | 1740 |
| Hydraulics | 1 single acting valve |
Options
| Description | Quantity | Article number |
|---|---|---|
| back to back flail blade - TR-LE.FBB100 | 96 | TR-LE.FBB100 |
| 3mm scarifier blade - TR-LE.FSC120 | 48 | TR-LE.FSC120 |
| Flail blade - TR-LE.FTW120 | 48 | TR-LE.FTW120 |
* Check availability in your region.
