Verti-Drain® 1517


The lightweight Verti-Drain® 1517 can work to a depth of 6” / 150mm and is well suited to sensitive turf surfaces. The belt driven machine operates a high speed while giving a neat and consistent hole pattern. An optional rear roller can be added to smooth the surface and leave a neat finish

High-speed machine
Lightweight machine with low HP requirements
Integrated parking stands for ease of operation
If additional working depth is required, consider the 22 Series Verti-Drain
SKU 111.215.017
Working width (m) 1.76
Working width (inch) 69
Max. Working depth (mm) 150
Max. Working depth (inch) 6
Working speed at hole spacing 65 mm 2.12
Working speed at hole spacing 2-1 2 inch (mph) 1.3
Weight (kg) 562
Weight (lbs) 1236
Hole distance with 12 mm tines (mm) 55
Hole distance with 1 2 x 6 inch tines (inch) 2.17
Hole spacing distance driving direction (mm) 25 - 125
Hole spacing distance driving direction (inch) 1
Max diameter solid tine (mm) 12 x 150
Max diameter solid tine (inch) 1/2 x 6
Max diameter hollow tine (mm) 19 x 150
Max diameter hollow tine (inch) 3/4 x 6
Min. Tractor HP required 28
Min. lifting capacity (kg) 750
Min. lifting capacity (LBS) 1653
Max. capacity with spacing 65 mm (m² hr) 3706
Max. capacity with spacing 2-1 2 inch (ft² hr) 39895
Three-point hitch 3-point CAT 1
Rpm Max. 540
Gear case oil 80W90 - 0.9 Liter
Lubricant EP 2
Dimensions (width mm) 970
Dimensions (height mm) 780
Dimensions (length mm) 2050
Dimensions (width inch) 38.2
Dimensions (height inch) 30.7
Dimensions (length inch) 80.7
Min. lifting capacity 610mm behind the lifting eyes (kg) 600
Min. lifting capacity 610mm behind the lifting eyes (lbs) 1322
Related
Description Quantity Article number
Toolbox with combi tool and manual 1
PTO Shaft 1
Storage Legs 1
Solid Tine 12x150mm (1/2x6") 32 311.112.150
Description Quantity Article number
Windrow Kit for 15 Series 1 211.215.006
Rear Roller Kit for Verti-Drain 1517 1 211.215.016
Turf Hold Down Kit for 12 mm tines 1 211.215.012
Turf Hold Down Kit for MTH 1 211.215.008
Solid Tine 5x125mm (3/16x5") 32 311.105.125
Requires
Adapter 5mm tines (3/16") 32 314.205.043

Solid Tine 8x95 (5/16x 3 13/16") 32 311.108.095
Requires
Adapter 8mm tines (5/16") 32 314.208.043

Solid Tine 8x95 (5/16x 3 13/16") 64 311.108.095
Requires
MTH Block complete 1513/1517 8 211.215.002

Solid Tine 8x150mm (5/16x6") 32 311.108.150
Requires
Adapter 8mm tines (5/16") 32 314.208.043

Solid Tine 8x150mm (5/16x6") 64 311.108.150
Requires
MTH Block complete 1513/1517 8 211.215.002

Solid Tine 10x100mm (3/8x4") 32 39200-447
Requires
Multi Coring Tine Head w/o tines 8 211.215.022

Hollow Tine 10x6x80mm (3/8x1/4x3") 32 311.210.080
Requires
Adapter 8mm tines (5/16") 32 314.208.043

Description Quantity Article number
Hollow Tine 10x6x80mm (3/8x1/4x3") 64 311.210.080
Requires
MTH Block complete 1513/1517 8 211.215.002

Hollow Tine 10x6x125mm (3/8x1/4 x 5") MD:8mm 32 311.210.127
Requires
Adapter 8mm tines (5/16") 32 314.208.043

Hollow Tine 10x6x125mm (3/8x1/4 x 5") MD:8mm 64 311.210.127
Requires
MTH Block complete 1513/1517 8 211.215.002

Hollow Tine 16/10x150mm (5/8x3/8x6") MD:12mm 32 311.216.150
Hollow Tine 19/12x150mm (5/8x3/8x6") MD:12mm 32 311.219.150
Hollow Tine 16/7x110mm (5/8x1/4x4 3/8") MD:19 ((top ejecting)) 32 311.219.138
Requires
Multi Coring Tine Head w/o tines 8 211.215.022

Hollow Tine 21x12x125mm (13/16x1/2x5") 32 9990075
Requires
Multi Coring Tine Head w/o tines 8 211.215.022

Hollow Tine 19x10x110mm (3/4x3/8x4 3/8") MD:19mm (top ejecting) 32 311.219.158
Requires
Multi Coring Tine Head w/o tines 8 211.215.022

Hollow Tine 19x10x125mm (3/4x3/8x5") MD:19mm 32 311.219.159
Requires
Multi Coring Tine Head w/o tines 8 211.215.022

Hollow Tine 19/12x150mm (5/8x3/8x6") MD:12mm 32 311.219.150
Requires
Multi Coring Tine Head w/o tines 8 211.215.022

Cross Tine 12x90mm (1/2x3 1/2") MD: 8mm 32 9990020
Requires
Adapter 8mm tines (5/16") 32 314.208.043

Cross Tine 12x90mm (1/2x3 1/2") MD: 8mm 64 9990020
Requires
MTH Block complete 1513/1517 8 211.215.002

Cross Tine 12x90mm (1/2x3 1/2") MD:12mm 32 311.812.090
Chisel Tine 4.8x19x120mm (3/16x3/4x4 3/4") MD:12mm 32 311.619.120
Chisel Tine 4.8x19x175mm (3/16x3/4x7") MD:12mm 32 311.619.175
Chisel Tine 5x30x90mm (3/16x1 3/16x3 1/2") MD:19mm 32 311.619.127
Requires
Multi Coring Tine Head w/o tines 8 211.215.022

Cross Tine 19x120mm (3/4x5") MD:12mm 32 9990021
* This product may not be available for your region - Redexim reserves the right to change specification of products without prior notice, specifications of equipment may vary globally - illustrations are for visual representation only.
